RCF ART 912-AX PROFESSIONAL ACTIVE BLUETOOTH® SPEAKER
£734.00
ART 912-AX is a top-notch solution for any audio application, featuring 48V microphone preamps and line inputs, an internal 6-channel digital mixer with advanced DSP, Bluetooth® stereo audio input, with dual speaker pairing option. The combination of a 1.75" compression driver, 12" woofer, and two-channel 2100W amplifier, produces 100° x 60° constant directivity coverage for the listening area with up to 130 dB SPL, distortion-free sound. The sleek cabinet uses a special polypropylene composite material with an M-brace internal reinforcement, making it easy to carry and secure to install on a pole, flown-, wall-, or truss-mounted using the multiple rigging points available.
Tech Spec
ACOUSTICAL SPECIFICATIONS
Frequency Response 50 Hz - 20000 Hz
Max SPL @ 1m 130 dB
Horizontal coverage angle 100°
Vertical coverage angle 60°
TRANSDUCERS
Compression Driver 1 x 1.0'', 1.75'' v.c
Woofer 12'', 2.5'' v.c
INPUT/OUTPUT SECTION
Input signal bal/unbal
Input connectors Combo XLR/Jack
Output connectors XLR
PROCESSOR SECTION
Crossover Frequencies 1600Hz
Protections Thermal, RMS
Soft Limiter
Controls Color touch panel, data entry/volume encoder, dedicated App for iOS and Android.
POWER SECTION
Total Power 2100 W Peak
High frequencies 700 W Peak
Low frequencies 1400 W Peak
Cooling Convection
Connections VDE
ELECTRONIC SPECIFICATIONS
Frequency Response 20 Hz - 20 Hz
THD+N, 20dB gain, 0dBu out 0.005% A-Weighted
PROCESSING
Processing Channels 6
Signal Processing 24 Bit
A/D-D/A conversion 32 Bit @ 48.0 kHz
Dynamic range 110
INPUTS Mic 2
Remote Controlled Storable Gain Yes
Gain Range 0 dB - 42 dB
Input Noise Level -114 dBu A-Weighted
Mic Inputs Impedance 6 kohm
Low Cut 20 Hz - 400 Hz
Phantom Power +48V Yes
Mono Line 2
Gain Selection 0 dB - 22 dB
Line Input Impedance 21 kohm
A/D Dynamic range 114 dB
Stereo Line 1
Gain Selection 0 dB - 10 dB
Stereo Line Input Impedance (kOhm) 13 kohm
OUTPUTS
Main MIX 1
OUTPUTS SPECIFICATIONS
Main Out Impedance 150 ohm
Main Out Level 22 dBu
D/A Dynamic Range 114 dB
COMPRESSORS
RCF Compressors
Compressors on MIC/LINE CH1 & CH2 Inputs.
EQ
Input Channels EQ 2 Shelving 1
3 Band EQ: High and Low band shelving, MID band peak on IN
5 Band EQ: 4 Full Parametric, 1 High Shelving and HPF 24 dB/Oct on Amplifier and MAIN output,
INTERNAL EFFECTS
Send Effects 1
MASTERING PROCESSORS
Main OUT type
MIX OUT, CROSSOVER OUT with RCF SUBWOOFERS presets, STEREO OUTPUT, CH1 LINK OUT.
STANDARD COMPLIANCE
Safety agency CE compliant
PHYSICAL SPECIFICATIONS
Cabinet/Case Material PP Composite
Hardware 1 x M10 top, 1 x M10 each side
Handles 1 top, 1 each side
Pole mount/Cap 35 mm insert
Grille Steel
Color Black
SIZE / WEIGHT
Height 642 mm / 25.28 inches
Width 370 mm / 14.57 inches
Depth 363 mm / 14.29 inches
Weight 18.7 kg / 41.23 lbs
SHIPPING INFORMATION
Package Height 685 mm / 26.97 inches
Package Width 423 mm / 16.65 inches
Package Depth 430 mm / 16.93 inches
Package Weight 22 kg / 48.5 lbs
Features
- Built-in 6-channel Digital Mixer
- Advanced User Interface w/ touch panel and remote control
- 1.75" Compression Driver and 12" Woofer
- Up to 130 dB Sound Pressure Level
- 2100W Class-D Bi-Amplification
- Dual combo preamp with 48V Power and Mini-jack stereo line input
- Bluetooth® stereo audio input, with dual speaker pairing option
- True Resistive Waveguide, FiRPHASE, and Bass Motion Control
