RCF ART 945-A PROFESSIONAL ACTIVE SPEAKER
£1,164.00
ART 945-A is masterfully engineered to deliver stellar audio performance and versatility for intensive audio applications. The combination of neodymium transducers - 4" titanium compression driver, 15" woofer - two-channel 2100W amplifier, and the constant directivity True Resistive Waveguide produces coherent 100° x 60° coverage for the listening area with up to 135 dB SPL, distortion-free sound. Merging RCF proprietary FiRPHASE and Bass Motion Control DSP processing, perfectly tuned for each model, the audience will experience absolute clarity and deep, powerful bass response. The sleek cabinet uses a special polypropylene composite material with an M-brace internal reinforcement, making it easy to carry and secure to install on a pole, flown-, wall-, or truss-mounted using the multiple rigging points available.
RCF ART 9 SERIES VIDEO
Tech Spec
ACOUSTICAL SPECIFICATIONS
Frequency Response 45 Hz - 20000 Hz
Max SPL @ 1m 135 dB
Horizontal coverage angle 100°
Vertical coverage angle 60°
TRANSDUCERS
Compression Driver 1 x 1.4'' neo, 4.0'' v.c
Woofer 1 x 15'' neo, 3.5'' v.c
INPUT/OUTPUT SECTION
Input signal bal/unbal
Input connectors XLR, Jack
Output connectors XLR
Input sensitivity -2 dBu/+4 dBu
PROCESSOR SECTION
Crossover Frequencies 650Hz
Protections Thermal, RMS
Soft Limiter
Controls Linear, Boost, Stage, Volume
POWER SECTION
Total Power 2100 W Peak
High frequencies 700 W Peak
Low frequencies 1400 W Peak
Cooling Convection
Connections Powercon TRUE1 TOP IN/OUT
STANDARD COMPLIANCE
Safety agency CE compliant
PHYSICAL SPECIFICATIONS
Cabinet/Case Material PP Composite
Hardware 1 x M10 Top, 1 x M10 each side
Handles 1 Top , 1 each side
Pole mount/Cap 35 mm insert
Grille Steel
Color Black
SIZE / WEIGHT
Height 717 mm / 28.23 inches
Width 415 mm / 16.34 inches
Depth 410 mm / 16.14 inches
Weight 22.4 kg / 49.38 lbs
SHIPPING INFORMATION
Package Height 760 mm / 29.92 inches
Package Width 475 mm / 18.7 inches
Package Depth 470 mm / 18.5 inches
Package Weight 26.2 kg / 57.76 lbs
Features
- Up to 135 dB Sound Pressure Level
- 2100W Class-D Bi-Amplification
- 45-20000 Hz linear frequency response
- 4" Titanium/Neodymium Compression Driver
- 15" Neodymium Woofer
- FiRPHASE zero degrees phase technology
- Bass Motion Control woofer excursion management
